ortofon

Ortofon 2M bronze moving magnet cartridge

$729.00
$729.00
Vision Living is an Authorized Reseller

2M Bronze

The 2M Bronze is designed to give the music a whole new dimension of precision. Listening to your records with the 2M Bronze is like hearing them for the first time, and you get to fall in love with the songs all over again. That is what hi-fi means to us, and that is what you get with the 2M Bronze.

Specifications

  • Channel balance at 1 kHz
    1 dB
  • Output voltage at 1 kHz, 5cm/sec
    5 mV
  • Channel separation at 1 kHz
    26 dB
  • Frequency response 20 Hz - 20 kHz
    2 / - 0 dB
  • Tracking ability at 315 Hz
    80 µm
  • Compliance, dynamic, lateral
    22 µm/mN
  • Cantilever material
    Aluminium
  • Stylus type
    Nude Fine Line
  • Stylus tip radius
    r/R 8/40 µm
  • Coil system
    Quad-coils with split pole pins and silver-plated OFC Coil wire
  • Tracking force range
    1.4-1.7 g (14-17 mN)
  • Tracking force, recommended
    1.5 g (15 mN)
  • Tracking angle
    20°
  • Internal impedance, DC resistance
    1.2 kOhm
  • Coil wire material
    Silver-plated OFC Coil Wire
  • Cartridge body material
    Polymer and aluminum
  • Cartridge colour
    Black/Bronze
  • Cartridge weight
    7.2 g
  • Premounted cartridge weight
    16.7 g
  • Recommended load resistance
    47 kOhm
  • Internal inductance
    630 mH
  • Recommended load capacitance
    150-300 pF
